Krist N Peyton , CO September 28, 2014 No error codes display blank and top blower not turning Ordered main control board and top blower. parts arrived as expected and well packaged. replaced main control board. Took two times to get ribbon cable inserted and aligned correctly. display functioned properly, but blower still not turning. replaced upper blower. everything working now. Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Richard S Greensboro , GA January 12, 2020 Appliance: Whirlpool 30" Built-In Electric Double Oven Convection-Upper Self-Clean (Gold Line) GBD307PRS01 This was a double oven, the lower cooling fan was making noise It was relatively easy to replace it. Some suggestions: 1. Make a platform to support the oven when you slide it out of the cabinet. Make the platform sturdy because this thing is heavy. Make the platform the same height as the cabinet so that you can just slide it out and back in without having to lift it. 2. The fan is secured with about 5 sheet metal screws plus there are 3 screws on the top that the fan slides under when you loosen them. However you can't fit a screw driver in the space to do the job. I had to use a plier to grip the round head screw and loosen it. That was difficult and took a long time. When I put the new fan in I replaced the 3 screws with hex head screws so that I could use small wrench to tighten them. 3. Of course turn off the circuit before you start. Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Pliers, Screwdrivers, Wrench Set
Melissa B Portland , OR December 07, 2016 Appliance: KitchenAid 30" Built-In Electric Double Oven Thermal Convection-Upper Self-Clean KEBC207KSS04 Loud and noisy double oven It needed a new blower motor. I ordered it and it arrived quickly. It took 2 people to lift out the double oven from the wall. Take off the sheet metal covering. Trade out the old blower motor, put it all back together and lift it back. Easy Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Duane J Glen Allen , VA September 23, 2017 Loud fans. I replaced with quiet fans, tada. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Roger A Davis , IL January 19, 2024 Appliance: KitchenAid 30" Built-In Electric Double Oven Self-Clean KEBC206KSS05 Kitchen Aid double oven replaced upper oven blower. Downloaded installation instructions to see how it was mounted in the wall cabinet. I built a plywood and 2x4 platform 30”x 32” that was level with the bottom of the double ovens. First turn off the power to the oven. Then once I removed the oven doors, racks and edge trim plus one piece of trim on the bottom, I could remove the four screws holding the ovens in the cabinet and then slide it out onto the wood platform. Now I could turn the ovens a little sideways to get at the back side and remove the back panel, then remove the old blower. Installed the new blower, replaced the back panel and slid the ovens back in the cabinet. I spent a little money and a couple hours building the platform, but it saved me a lot of heavy lifting and prevented possible damage to the cabinet or the ovens. Even my wife said how great the platform worked. The upper oven when baking would expel a lot of moisture, water vapor on the wood cabinet above and would have eventually ruined the cabinet. I found that the old upper blower was seized. Now with the new blower installed everything works fine. The Wife is happy again. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
