Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Refrigerator Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number WP2259350 replaces AP6006874, 2259350, 1016717, PS11739961.
Description
This electronic power supply board converts incoming AC power to the low-voltage DC used by the refrigerator's controls and components. Replacing a failed board restores stable power to the UI, fans, lights, and cooling functions.
- Converts line voltage to regulated low-voltage DC for control electronics
- Distributes power to the main control, display, sensors, fans, and valve/relay circuits
- Common signs include a blank or non-responsive control panel, no interior lights or dispenser, intermittent power/clicking, or the unit not running even though the outlet has power
- Failures may follow electrical surges or shorted loads
What's included: 1 power supply board Install notes:
- Disconnect power at the breaker or unplug before servicing; capacitors may hold a charge
- Use ESD protection and handle the board by its edges
- Photograph/label all connectors; transfer wires one by one and ensure full seating
- Mount securely and inspect for pinched/shorted wires before restoring power
