Whirlpool WPW10170531 Orifice Spud OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related and Range / Cooktop / Oven Gas Conv Kit.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10170531 replaces AP6016211, W10170531, 1471170, PS11749495, W10407540.

Description

This orifice spud meters gas to a burner on your range or cooktop, setting proper flame size for efficient, even heating. Replacing a damaged or incorrect spud restores consistent burner performance and flame quality.

• Meters gas flow through the burner orifice to control flame height and shape
• Supports efficient combustion and consistent heat output
• Common fix for flames that are too high/low, yellow/sooty, or uneven
• Used when setting up or converting a model for the specified fuel type (LP or natural), per the position of each burner

What's included: One orifice spud Install notes:

• Shut off the gas supply and disconnect electrical power before servicing
• Remove the burner cap and head to access the spud; lift the cooktop or open the range top if required
• Remove/install with a properly sized wrench; do not overtighten. Apply thread sealant only if specified by the manufacturer
• Match each spud to the correct burner and fuel type per your model documentation; after reassembly, restore gas and leak-test with a soapy-water solution
