Whirlpool W10758273 Broil Burner Orifice (Lp), 1 OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10758273 replaces AP5956770, 3436921, PS10064587, W10465080.

Description

This LP broil burner orifice precisely meters propane to the oven's broiler. Replacing a damaged or incorrect orifice restores proper flame size and reliable ignition on LP fuel for consistent, efficient broiling performance.

• Regulates gas flow to the broil burner when using LP (propane) fuel
• Helps ensure correct flame size/shape for even broiling heat
• Can address weak or uneven broil flame or yellow/sooty flames
• May help resolve a broiler that won't ignite or won't stay lit

What's included: 1 LP broil burner orifice Installation notes:

• Disconnect power and shut off the gas supply; allow the appliance to cool completely.
• Access the broil burner/orifice per the manufacturer's instructions. Remove the old orifice and hand-thread the new one; snug gently—do not overtighten.
• Restore gas and check all connections for leaks using a non-corrosive leak-detection solution; never use an open flame.
• Use only on LP systems. If converting fuel types, adjust the regulator and air shutters as specified.
