Whirlpool W10480126 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10480126 replaces AP5629838, 2312655, PS3653300, W10405856, W10445278.

Description

This electronic control board is the appliance's central brain, interpreting user inputs and directing power to key components. Replacing a failed board restores responsive controls, accurate cycle timing, and consistent, reliable operation.

• Manages cycle timing and switches power to motors, valves, heaters, and other loads
• Interprets signals from the user interface and sensors/safety interlocks
• Coordinates programs and diagnostics to protect components and ensure proper operation
• Common symptoms of a failed board include no start, dead or blank display, unresponsive buttons, cycle not advancing, error codes, or intermittent operation

What's included: One electronic control board. Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Use ESD precautions; handle the board by the edges and avoid touching components
• Photograph wiring and move connectors one at a time to the new board to ensure correct placement
• Follow your model's tech sheet for any required setup, diagnostics, or calibration after installation
