Whirlpool W10480317 Electronic Control Board (Oven/Range Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10480317 replaces AP5629843, 2312665, PS3653310, W10436367, W10442488.

Description

This electronic control board manages the oven/range user interface and cooking functions so the appliance responds correctly to touchpad inputs, timers, and bake/broil commands. Replaces a failed control to restore reliable cycle control and display operation. What it does:

• Receives and processes commands from the touchpad/controls to run bake, broil, timer and other oven functions
• Sends signals to relays and heating elements to control temperature and cooking cycles
• Provides the clock and timer display and accepts user input for settings
• Failsafe symptom linkage: use when display is blank, touchpad unresponsive, incorrect heating, or oven won't start

What's included:

• One electronic control board

Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Handle the board carefully and avoid electrostatic discharge; ground yourself before touching contacts
