Whirlpool W10581897 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10581897 replaces AP5803401, 3022842, PS8768789.

Description

This electronic control board is the central "brain" of the appliance. It processes sensor inputs and directs power to key components so cycles run correctly. Replacing a failed board restores normal operation and responsive controls. What it does

• Distributes power to motors, valves, heaters, fans, and displays based on sensor signals
• Manages cycle timing, modes, and overall system logic
• Stores error logic and supports service diagnostics
• Helps protect the system by shutting down functions when faults are detected
• Common symptoms include no power or no response, intermittent operation, error codes/alarms, or components not running

What's included

• 1 electronic control board

Install notes

• Disconnect power before servicing; observe ESD precautions and handle the board by the edges
• Photograph connections and move wire harnesses one at a time to the new board; confirm connector orientation and seating
• Transfer any jumpers, DIP switch positions, brackets, or mounting hardware from the original board as needed
• After installation, restore power and run the model's diagnostic or configuration steps per the tech sheet/service manual if applicable
