Whirlpool W10817282 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Dishwasher Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10817282 replaces AP6004426, W11025862, W10752859, 4392839, PS11737836, W10546454, W10568522, W10588610, W10589070, W10608639, W10635102, W10671917, W10711377, W10756246, W10804124, W10814355.

Description

This electronic control board is the appliance's central command module, directing power and timing so functions run correctly. Replacing a failed board helps restore normal operation when the unit is unresponsive or behaves erratically.

• Manages power and timing to components based on selected settings
• Interprets inputs from sensors/switches to control each step of the cycle
• Common symptoms: won't power on or start, unresponsive controls, random stopping, error codes/alarms

What's included: 1 electronic control board Installation notes:

• Disconnect power before service; use ESD protection and handle the board by its edges
• Photograph wire/harness connections and transfer connectors one at a time
• Inspect and correct any shorted components or damaged wiring before powering up the new board
• After installation, follow the unit's tech sheet for any required tests, calibration, or programming steps
