Whirlpool W10906422 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Dishwasher Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10906422 replaces AP6034555, W10804122, 4456029, PS11769628, W10834731, W10876143.

Description

The electronic control board is the appliance's main control module. It interprets inputs from the user interface and sensors, then powers and times key components to run each cycle. Replacing a failed board restores reliable, predictable operation.

• Coordinates cycle sequencing and powers components through onboard relays
• Receives signals from switches/sensors and manages overall operation
• Common failure symptoms: unresponsive controls or no power
• Won't start, stops mid-cycle, or won't advance through a cycle
• Intermittent operation, flashing lights, or fault/error codes tied to the main control

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker before servicing; verify the unit is de-energized
• Use ESD protection; handle the board by the edges to avoid static damage
• Photograph/label wiring and move connectors one at a time to the matching terminals
• After installation, run the appliance's diagnostic/test cycle to confirm proper operation
