Whirlpool W11202742 Electronic Control Board (Main Console Board) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11202742 replaces AP6287174, WPW10298340, W10254542, W10298340, 4844301, PS12349159.

Description

An electronic control board that manages cycle selection, timing and user controls so your appliance responds correctly to settings and sensor input. Replacing a faulty board restores reliable control and cycle operation. What it does:

• Acts as the appliance's brain, sending power and signals to motors, valves and sensors
• Interprets user commands from the console and starts or advances cycles
• Controls timers, display readouts and cycle logic based on sensor feedback
• Can stop erratic behavior caused by shorted or failed circuitry (unresponsive buttons, cycles that won't start or stop, or incorrect cycle selection)

What's included: One electronic control board. Install notes:

• Disconnect power before starting; work only with the appliance fully de-energized
• Replacement typically requires removing the control console or access panel and unplugging/replugging wire harnesses
• Handle the board by the edges and avoid touching components or connector pins
