Whirlpool W10842325 Detergent And Rinse Aid Dispenser Assembly (Dishwasher) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Fuse Or Sensor and Washer Screws, Nuts, Washers.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10842325 replaces AP5988855, W10628740, 4363586, PS11728067, W10250734, W10368769, W10376678, W10549925, W10628743, W10628744, W10760820, W10817719.

Description

This door-mounted dispenser stores and releases detergent and rinse aid at the correct times during the cycle, helping restore consistent cleaning and drying results. Replace a worn or damaged unit to fix soap door and rinse aid issues.

• Holds detergent for the main wash and opens the cup during the programmed step
• Meters rinse aid into the final rinse to reduce spotting and improve drying
• Helps resolve symptoms like detergent left in the cup, soap door won't latch/open, leaking rinse aid, or poor cleaning performance
• Direct replacement for the original door dispenser assembly

Install notes:

• Disconnect power to the dishwasher before servicing
• Remove the inner door panel to access the dispenser; disconnect the wire harness
• Release the retaining tabs/screws, remove the old dispenser, and clean the sealing surface
• Seat the new dispenser flush, tighten mounting screws evenly, reconnect wiring, and run a test cycle to check for leaks and proper operation
