Whirlpool WP9755770 Bake Element (Lower Oven) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP9755770 replaces AP6013936, 9755770, W10308474, 1060998, PS11747168.

Description

This bake element is the lower heating coil that provides the oven's primary heat during Bake. Replacing a worn or burned-out element restores fast preheats and consistent cooking results in electric ranges/ovens.

• Provides bottom heat for the Bake cycle to preheat and maintain set temperature
• Common symptoms: no heat on Bake, very long preheat, uneven/undercooked results, or visible blisters, splits, or burn marks on the element
• If Broil still heats but Bake does not, the bake element is a likely failure point

Includes: 1 bake element Installation notes:

• Disconnect power by unplugging the appliance or switching off the circuit breaker
• Remove oven racks; take out the element's mounting screws, then gently pull the element forward and disconnect the two wire terminals
• Support the wires to prevent them from slipping back into the rear cavity; position the new element and secure with the mounting screws
• Restore power and test a Bake cycle
