Whirlpool W11101534 Broil Element (Upper Oven) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11101534 replaces AP6238052, W10249979, 4534476, PS12074644.

Description

This broil element replaces the upper heating element in electric ovens to restore broiling and top-heat cooking performance. It provides the heating surface used for browning, searing, and finishing dishes under the oven broiler. What it does

• Replaces a damaged or burned-out upper broil element to restore broiling heat
• Heats from the top of the oven for browning, melting, and finishing foods
• Common symptom: broiler cycles but fails to heat, produces no or weak top heat
• Also used when the element shows visible damage, breaks, or sparks

What's included

• One upper broil element

Install notes

• Disconnect power to the appliance before starting—verify power is off at the breaker
• Allow the oven to cool completely and handle the element by insulated areas only
• Remove the oven racks and access the element mounting screws/terminals; support the element when disconnecting wiring
• Test fit and power up briefly to confirm operation after installation
