Whirlpool W10539841 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Microwave Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10539841 replaces AP5671035, 3021557, PS7320906, W10269479.

Description

This wire harness assembly routes power and control signals between the appliance's main control and its components to restore reliable electrical connections. It replaces a damaged or intermittent wiring assembly to help components receive proper power and signals. What it does

• Connects the main control to heating elements, sensors, switches, or other components depending on appliance model
• Restores lost or intermittent power/signal paths caused by frayed, burned, or broken wires
• Helps resolve symptoms like components not powering, intermittent operation, or electrical arcing at connection points
• Maintains correct wire routing and connector fit for safe operation when installed properly

What's included One wire harness assembly Install notes

• Disconnect all power (unplug or switch off breaker) before beginning work
• Photograph existing routing and connector locations to ensure correct reinstallation
• Route harness without pinching; secure with original clips or ties and avoid heat sources
