Whirlpool W10837236 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10837236 replaces AP5988715, 4363313, PS11727920, W10537498.

Description

This wire harness assembly routes power and signals between appliance components to restore electrical connectivity and reliable operation. It replaces a damaged or worn wiring assembly to help resolve intermittent power, control, or component failures. What it does:

• Carries power and control signals between the control, motors, sensors and other electrical components
• Replaces frayed, burned, or broken wiring that can cause intermittent operation or no power to affected parts
• Helps address symptoms such as no start, unresponsive controls, or certain component functions not working
• Restores factory wiring routing and connector fit for safe, reliable connections

What's included:

• One wire harness assembly

Install notes:

• Disconnect power (unplug or shut off breaker) before beginning any repair
• Take photos or label connectors before removal to ensure correct reconnection
• Route the harness clear of moving parts, sharp edges, and heat sources; secure with existing clips or fasteners
• If corrosion or connector damage is present, clean or replace affected terminals to ensure good contact
