Whirlpool W11084324 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11084324 replaces AP6048036, W10297482, 4534077, PS12070569, W10281330.

Description

This wire harness assembly connects key electrical components to restore proper power and signal flow in the appliance. Replacing a faulty harness helps stop intermittent operation and restores reliable control function. What it does:

• Provides the factory routing and connections between controls, switches, and motors.
• Re-establishes power and signal paths to prevent intermittent or no-power symptoms.
• Stops failures caused by broken, burnt, or loose wires and terminals.
• Ensures secure plug-to-plug connections using original-style terminals.

What's included: One complete wire harness assembly as shown. Install notes:

• Disconnect the appliance from power (and water if applicable) before starting.
• Inspect connectors and routing; replace only if matching the original harness.
• Reuse any mounting clips or grommets; secure wires away from heat and moving parts.
