Whirlpool W10646418 Door Hinge (Lower, Freezer) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10646418 replaces AP5952727, WPW10414753, 3450561, PS10059892, W10414753.

Description

This door hinge mounts at the bottom of the freezer door, supporting its weight and providing the pivot point for smooth operation. Replacing a worn hinge restores proper alignment and sealing to help prevent frost and temperature issues.

• Supports the freezer door at the lower pivot for smooth opening and closing
• Helps maintain door alignment so the gasket seals correctly
• Wear can lead to sagging, rubbing, or gaps along the hinge side
• Helps resolve poor sealing, frost buildup, or the door popping back open

What's included: 1 door hinge

• Disconnect power and remove the base grille before servicing
• Support the door to prevent dropping; mark hinge position for easier realignment
• Remove hinge screws; transfer any shims/spacers from the old hinge to the new one
• Reinstall, tighten fasteners, and check door swing and gasket contact; adjust as needed
