Whirlpool WP74011141 Range Oven Door Hinge OEM Part

I replaced the hinge due to the hinge spring breaking. To replace the hinge you do the following: 1. Disconnect power to stove, either at circuit box or at outlet. 2. Lift door off of outside hinge arms ; no screws are used to attach the door to the hinge 3. Remove two screw on under side of cook top, one on each side. 4. Disconnect cook top connector. 5. Lift cook top off 6. Remove screws from top rail of stove that hold the side panel. 7. Remove the screw on the back that hold the side panel on. 8. Remove end cap 9. Lift side panel off of upper and lower pins 10. Remove front screw holding hinge. 11. Remove broken hinge. 12. Install new hinge 13. Replace stove panel, cooktop and door in reverse of removal steps. That's how I did it. It took about 20 minutes.

Left side oven door hinge broke but order two hinges for replacement. Parts arrived in two days as indicated when order was placed. Removed a/c power and turned off gas. Removed gas stove top burners, 4 screws holding gas orifice assembly under stove top, pulled top forward, released front spring clips lifting top off and slid top to right top side of stove for access to left side panel with out disconnecting the burner electrode electrical wires. Removed left side panel for direct access to left hinge. Removed 2 hex screws holding hinge and replaced. Repeated process for the right side hinge. The repair was faster than cleaning the stove since it was apart with easy access.

Our Maytag oven door was really squeakey, I mean loud. I tried every lubricant available without success. I then thought about replacing the two door hinge/springs. I googled and ordered the hinges. In less than 48 hours they were delivered. Just two bolts each side and the old hinges dropped out. The new hinges bolted on easily, and we now have a silent oven door. Appliance Parts Pros are the best!

2 new door hinges.

I turned off my stove circuit breaker first. Then I unplugged the stove and brought it out into the kitchen for easy access. Next I removed the back panel by removing several screws. After that I was able to unplug two wiring connectors that led to the stove top. (mine is a glass flat top stove) Next I removed the oven door by opening a few inches and pulling up and off. Then I removed the two corner screws that hold the cook top on, and removed the entire cook top to set aside. Next I removed the screws that hold both of the side panels on. I also had to remove a total of 4 screws that were at the control panel corners to gain access. The side panels pull out at the bottom and then slide up and off of pins. Then it was easy to remove the hinges and replace. Only 2 screws hold each hinge on. They pull out of the opening towards the back of the stove. Reverse procedure to reassemble.
