Whirlpool WPW10324089 Ice Bin Assembly OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Auger, Helix, Crusher, Refrigerator Ice Bin, Bucket, Or Tray and Refrigerator Ice Maker & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10324089 replaces AP6019563, W10324089, 13012602, 13012609, 1877214, PS11752872, W10165971.

Description

This ice bin assembly stores the cubes your icemaker produces and makes them easy to access or dispense. Replacing a cracked or worn bin prevents spills and jams and keeps your refrigerator's ice service working smoothly.

• Collects and holds ice produced by the icemaker
• Slides in and out for convenient ice access
• Helps prevent stray cubes and spills inside the freezer
• Common symptoms of failure: cracked or broken bin, ice spilling, difficulty dispensing or removing ice

What's included: One ice bin assembly Install notes:

• Disconnect power before servicing for safety
• Empty and remove the old bin per your model's procedure
• Seat the new bin fully on its rails or locator tabs
• Restore power, make a small batch of ice, and check operation
