Whirlpool 5765M480-60 Oven Control Panel Assembly OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Touch Pad.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 5765M480-60 replaces AP4427091, 5765M436-60, 5765M438-60, 5765M439-60, W10289883, 1543999, 5765A439-60, 74008783, 74008784, 74008786, 74008787, AH2357949, EA2357949, PS2357949.

Description

Each piece is sold separately from the unit. This part is a Whirlpool oven control panel assembly. The control panel assembly and control board act as one unit to make up the central command center of the oven. The front-facing area contains the dials visible to the user, and the rear houses the actual circuit board. When a control panel assembly or the control board malfunction, the oven is essentially out of commission. In some cases, the malfunction may be gradual, with specific settings and functions going out one at a time. If burners begin to short out individually, or certain functions cannot be toggled on or off, it may be time for a replacement control board assembly.Installation of the part on compatible models is fairly simple. There is one screw on each side of the control panel assembly on the front of the oven. Remove these screws and the control panel should slide off with ease. There are two connecting wire harness components on either side of the control panel. Remove these connections and replace with the new control board, and pop it back into place before replacing the screws. This component can be used with Whirlpool or Maytag appliances. It is a genuine OEM product sourced directly from the manufacturer.
