Whirlpool W11664709 Grooved Pin (Retaining Fastener) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11664709 replaces AP7212749, WP9704677, 9704677, W11533778.

Description

This small grooved pin is a precision retaining fastener used to secure and align mating parts within an appliance assembly. Replacing a worn or missing pin restores proper support and helps the mechanism operate smoothly and quietly. What it does:

• Locks two components together with an interference-fit groove to prevent unwanted movement
• Maintains alignment of hinges, linkages, or levers in the assembly
• Reduces wobble, vibration, and rattling that can occur when a pin is worn or missing
• Common symptoms include loose or drifting parts, misalignment, intermittent operation, or unusual noises

What's included:

• 1 grooved pin

Install notes:

• Disconnect power and, if applicable, shut off water/gas before servicing
• Support the assembly; remove any retainers, then drive out the old pin with a small punch/drift and install the new pin aligned to the original orientation
• Do not reuse damaged hardware; replace worn bushings or clips and ensure smooth movement
• Test operation before reassembling covers and restoring power
