Stephen B Shelby , NC January 14, 2019 Drain pump was not working due to broken glass in the bottom of the dishwasher I tipped the dishwasher over and replaced the drain pump. Very simple replacement. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Adjustable Wrench, Pliers
Ken L Nutley , NJ January 20, 2019 Appliance: Whirlpool Dishwasher WDF520PADM5 Drain hose with check valve wasn't working and the drain pump wasn't working Replaced the drain pump and drain hose and the problem was fixed. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Pliers, Screwdrivers
Michael C Monroe , WI July 21, 2017 Appliance: Whirlpool Dishwasher, Portable WDP340PAFW0 Discharge hose kept getting clogged Suspected that the discharge/sump pump was not working at peak performance. Put the new one on, and connected the shop-vac back up to the sink end, and viola -- hose was cleaned out! Because only a small amount came out, I'm certain that the pump was the issue. The friction pads were easy peasy. Just took out a couple of screws, removed the springs & extensions, and slipped on the new ones --- NICE! Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Screwdrivers, Socket Set
Don C Santa Fe , NM December 09, 2025 Drain pump failure Replaced drain pump Read More... Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Pliers, Screwdrivers
Jennifer B Denham Springs , LA May 11, 2026 Dishwasher would not drain Dishwasher stopped draining at the end of a cycle, leaving water and detergent in the tub. We replaced the drain pump following instructions from the video on the website. The old pump had shard of glass wedged under the impeller. The most time consuming part of the repair involved disconnecting then reconnecting the water and drain lines, and removing/replacing dishwasher from counter. Actual pump replacement required no tools and took only a couple of minutes. This DIY repair saved me a diagnostic fee of $139, not to mention the actual cost for the part and labor. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Wrench Set
