Whirlpool WPW10195007 Inner Door Seal (Dishwasher) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10195007 replaces AP6016731, W10195007, 4442076, PS11750024.

Description

This inner door seal forms a moisture barrier between the dishwasher tub and the door assembly, helping keep wash water and steam contained. Replacing a worn seal can stop drips at the door and protect internal components.

• Seals the joint along the inner door to contain wash water and steam
• Helps prevent door-area leaks or drips during cycles
• Blocks moisture from entering the door cavity where electrical parts reside
• Common signs: water at the bottom/sides of the door, damp control area, visible wear/flattening or tears on the seal

What's included: 1 inner door seal Install notes:

• Disconnect power and turn off water supply before servicing
• Open the door and remove perimeter screws to separate inner/outer door panels
• Remove the old seal; clean the mounting surface and note seal orientation
• Press the new seal firmly into place, reassemble, and run a leak check
