Whirlpool 22003614 Shield, Motor Control Board (Protective Cover) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Guard, Shield, Barrier.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 22003614 replaces AP4029109, 893854, AH2021172, EA2021172, PS2021172.

Description

This motor control board shield is a protective cover that helps guard the appliance's control electronics from heat, debris and accidental contact. Replacing a damaged shield helps reduce risk of shorts and keeps the control board installed correctly. What it does:

• Covers and protects the motor control board from dirt, lint, heat and accidental contact
• Helps prevent electrical shorts or intermittent connections caused by debris or physical damage
• Restores proper mounting and alignment for the control board if the original shield is cracked, warped or missing
• Can reduce issues that present as erratic motor behavior or control-related error codes when the board is exposed

What's included:

• One motor control board shield

Install notes:

• Always unplug the appliance before starting work and discharge any stored energy per manufacturer guidance
• Handle the control board and connectors carefully; avoid touching circuit traces or components
• Reuse the original fasteners when possible and ensure the shield is fully seated and secured to prevent contact with moving parts
• If the control board shows signs of damage (burn marks, melted components, visible faults), replace the board rather than relying on the shield alone
