Whirlpool WP2223320 Pan Slide OEM Part

Removed trays. Trap broken tracks back to notch in order up lock and remove them. in stalled new replacement tracks but first sand down flat the two circular taps that were no allowing the tracks two get flush with the wall surface. Clean wall surface of any build up spills. rub on a light coat of liquid soap which will help you slide the track in and seats.

Just insert in the support and done.

Remove the drawer, remove the shelf bracket from the back of the refrigerator, it simply lifts out at an upward angle like any normal shelf bracket; remove the broken pan slide by sliding it “forwards” out of the tabs locking it into place; if it is tight, gently encourage it to move with a slight tap (light hammer etc). Align the new pan slide into the holes (be sure to properly orient the slide). And then slide it back to lock it into place. Replace the shelf bracket and the drawer.... Easy

1. Pulled the drawer out and lifted out the adjustable glass tray with the cracked track attached. 2. Replacement part had a couple of little round plastic stops molded in at each end of the part. 3. Part wouldn't fit in the tracks due to the molded stops. 4. Did an engineering fix by grinding down both molded stops using a very small bench grinder. 5. New [modified] track fit perfectly. 6. Parts back in the fridge.

I replaced the water inlet valve & both dispenser levers (water & ice) and adjusted the lever locking spring.
