Whirlpool W11160346 Orifice Spud (Burner Orifice Holder) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11160346 replaces AP6333207, W10324014.

Description

This orifice spud secures the burner orifice and helps deliver gas to the burner for proper ignition and flame. It replaces a damaged or worn spud to restore stable burner operation and consistent cooking performance. What it does:

• Holds the burner orifice in the correct position for a steady, controlled gas flow
• Directs gas from the valve to the burner for reliable ignition
• Replaces cracked, corroded, or misshapen spuds that can cause uneven flames or poor burner performance
• Helps maintain consistent heat across the burner when installed correctly

What's included:

• One orifice spud

Install notes:

• Turn off gas supply and power to the appliance before starting any repair
• Only reinstall if threads and sealing surfaces are clean and undamaged; replace associated gaskets or fittings if specified
• Hand-start threaded fittings, then tighten to OEM torque; avoid overtightening which can damage the spud
