Whirlpool W11160347 Orifice Spud (Burner Gas Fitting) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11160347 replaces AP6333208, W10407675.

Description

This orifice spud is the small gas fitting that directs fuel from the valve to the burner, helping produce a consistent, controllable flame for safe cooking. Replace a damaged spud to restore proper burner operation. What it does

• Channels gas from the valve to the burner cap for correct flame delivery.
• Helps maintain steady, even burner flames when functioning properly.
• Commonly replaced when burners have low or uneven flames or fail to light reliably.
• Works with the burner assembly as part of the fuel delivery path.

What's included

• One orifice spud

Install notes

• Turn off gas supply and electrical power to the appliance before starting.
• Remove burner components as needed, swap the spud, and reassemble in reverse order.
• After installation, check for gas leaks with a safe leak-test method (soapy water) and restore power only when no leaks are present.
