Whirlpool W10892065 Start Device (Compressor) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10892065 replaces AP6030710, WPW10330832, W10330832, 4460540, PS11765759, W10796741.

Description

This compressor start device plugs onto the compressor terminals to help it start and run reliably. Replacing a weak start device can restore cooling performance and stop repeated clicking or short-cycling when the compressor tries to start. What it does:

• Provides the initial power path to start the compressor motor
• Works with the overload protector to help safeguard the compressor during high current/overheat conditions
• Fixes: refrigerator not cooling or warming temperatures
• Fixes: rapid clicking from the rear as the compressor attempts to start
• Fixes: compressor starts then stops after a few seconds

What's included:

• One start device assembly

Install notes:

• Disconnect power before servicing; pull the unit forward and remove the rear access panel if present
• Note wire orientation; pull the old start device straight off the compressor pins and push the new device on fully in the same orientation
• Ensure all connectors are fully seated and any retainers are secure before restoring power
• If your model uses a separate run capacitor or overload protector, transfer/reconnect those components as originally installed
