Whirlpool W11568973 High-Limit Thermostat (205°F) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11568973 replaces AP7179163, 3388697.

Description

High-limit thermostat that monitors appliance temperature and cuts power to the heating element at 205°F to prevent overheating. Replaces a failed hi-limit control to restore safe heater operation. What it does:

• Opens at 205°F to stop heat flow and protect the appliance from overheating.
• Stops the heating element when the thermostat is open; allows heat when closed.
• Common symptoms indicating a failed hi-limit: no heat, intermittent heating, or unexpected overheating.
• Acts as a safety cut-out to protect wiring and components from excessive temperature.

What's included: One high-limit thermostat. Install notes:

• Disconnect power to the appliance and allow it to cool before starting any repairs.
• Replace with a like-for-like 205°F hi-limit thermostat and reconnect wires to matching terminals.
• Check connectors and wiring for heat damage; replace any compromised parts before reassembly.
