Ronald F Brighton , MI December 14, 2020 Water leaking from under dishwasher first thought to be this motor to sump seal or the seal in the sump to the diverter motor Leak was from the diverter motor shaft internal seal leaking. Replaced the diverter motor which fixed the leak. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Pliers, Screwdrivers
Scott A Canton , GA July 23, 2021 Leaking diverter motor seal Replaced the sump and diverter motor at the same time. A pretty simple repair just take a picture or two before you start, remove the wires and start removing the parts so you can remove the sump. Everything went back together very well and I have ran three wash cycles to validate no leaks before putting the trim kit back. Very happy. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Adjustable Wrench, Pliers, Screwdrivers
Frank M Wilmington , MA November 04, 2019 Yup Replaced the motor and sump assembly because each of the shaft seals had failed. The seal inside the motor slid down out of position and the seal in the sump where the shaft motor goes through was suspect. Replaced both and the discharge motor seal. Parts were awesome. Delivery time awesome and everything works as it should. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Nut Drivers, Screwdrivers, Socket Set
