Jon K Bellevue , NE February 23, 2020 Bottom track was worn out on left hand side Removed the bottom rack from the dishwasher. Removed the 2 front plates at bottom of the dishwasher. Removed the two screws from the top of the dishwasher holding the dishwasher to the counter-top. Pulled the dishwasher out. Removed the 8 mm screws from the outside of the dishwasher-- 4 per side (Underneath the sound proofing). Pulled the old tracks and placed the new tracks into place and tightened the screws back up. Pushed the dishwasher back into place. Reinstalled the screws securing the dishwasher to the counter-top. Replaced the 2 front plates at bottom of the dishwasher. Replaced the bottom rack. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Screwdrivers
Colleen A Middleboro , MA December 09, 2019 The bottom tracks were no good The fix was easy. It took about half an hour to do. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Pliers, Screwdrivers
Todd D Chaska , MN September 19, 2022 Appliance: KitchenAid Dishwasher KDTM404ESS2 Left side dishrack track broken. Replaced the track altogether and found the pivot point on the front slider had broken off together. At the same time, replaced both dishrack supports and the silverware basket as the original had holes in it and silverware would fall through the basket. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Pliers, Screwdrivers, Socket Set
Mark A Washington , MI October 26, 2025 Broken dishrack support bracket Swapping old for new brackets was easy after studying how the old ones were attached. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes
Kenneth L Lakeway , TX December 11, 2017 Tack for lower rack on Kitchenaid dishwasher froze in the extended position. Replaced both left and right tracks and support pieces which connect tracks to dish basket. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Socket Set, Wrench Set
