Whirlpool WPW10270254 Top Burner Infinite Switch (Hiper) OEM Part

I purchased a replaced switch and installed it in the cook-top.

Simple 10 minute swap out. Power off the cook top, removed the knob and rubber seal, used a small phillips screwdriver to remove the 2 screws securing the switch, removed access cover below and pulled the defective switch out, replace the gasket on the new switch and reconnect the wires. Position the new switch in the panel noting that the D shape must be oriented correctly and secure the 2 phillips screws. Re-attatch the access panel, replace the rubber seal and knob. Power the cook top up. Worked perfectly.

I replaced the switch and the knob using only a screwdriver type handheld multi-tool. My friend had called me on 24 December because his cooktop was tripping the breaker. Since I was out of town and could not get over there, he came over to my house to use my cooktop and all went well. Just before New Year’s Day 2020 I went over and diagnosed the problem. Then over the next couple of days discovered appliance parts pros and ordered the part that was delivered Jan 10. I went over and replaced the switch, replaced the knob and all went well.

Replace the switch, it was very easy it save me a lot of money

Replaced the switch.
