Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Washer Switch.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number 285935 replaces AP3607689, 1016892, 3935737, 3966402, AH871335, EA871335, PS871335.
Description
This lid switch detects when the washer lid is closed and signals the control to allow motor operation. Replacing a faulty switch restores normal cycle starts and the washer's safety interlock. What it does:
- Detects lid position and completes the electrical circuit so the washer can start and run.
- Acts as the safety interlock that prevents the motor from running with the lid open.
- A failing switch can prevent the washer from starting, stop spin or agitation, or cause cycles to stop unexpectedly.
- Replaces the lid-actuated switch used in top-load washers' control/interlock system.
What's included: One lid switch. Install notes:
- Disconnect power at the breaker or unplug the appliance before beginning work.
- May require removing the washer top or control panel to access the switch—keep track of fasteners and connectors.
- Handle electrical connectors gently and verify connections are secure; test the new switch only after restoring power per manufacturer guidance.
