Whirlpool W11103599 Temperature Selector Switch (Rotary) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11103599 replaces AP6237529, W10114118, WPW10114118, 4534517, PS12074684, W10913964.

Description

This rotary temperature selector switch mounts in the console and lets you choose the temperature setting for a cycle. Replacing a worn switch restores accurate response to the control knob so the appliance follows the temperature you select.

• Converts the knob position into the correct electrical output for the chosen temperature level
• Helps ensure the appliance responds to the temperature setting selected on the control panel
• Common symptoms: only one temperature works, temperature won't change with the knob, selector feels loose or won't "click," intermittent temperature selection
• Typical causes include worn internal contacts or a damaged switch shaft

What's included: 1 temperature selector switch Install notes:

• Disconnect power before servicing
• Access the control console; remove the knob and retainers to free the switch
• Photograph or label wire positions, then transfer connectors to the new switch one at a time
• Secure the switch, reinstall the knob/panel, restore power, and test temperature selection
