Tomas S American Canyon , CA November 04, 2015 Appliance: Model WOS51ECOABO1 Whirlpool wall oven lost power while in self cleaning mode door locked and no display model #wos51ecoabo1 Replaced the thermst-fix and the thermal fuse oven now works great Read More... 7 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Isam Y Williamsburg , VA January 28, 2017 Appliance: Model WHIRLPOOL OVEN Whirlpool oven thermal fuse tripped I replaced all three thermal fuses even though I believe two of them were okay. It was easy. All I had to do was extract the double oven from the wall (that was the hardest part). I put it on some cardboard to protect my floor. Then I took off three panels with about 40 screws. There was one fuse on the back of each oven and other up by the motherboard. The parts took about 5 minutes to replace and another hour to put it all together again. Easy and I am not a mechanic. Saved me much money. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Pliers, Screwdrivers
Charlie C San Luis Obispo , CA April 23, 2018 After self cleaning cycle our Kitchenaide oven quit working Between YouTube, a multimeter and Appliance Parts Pro I was able to diagnose the problem and fix the oven without an expensive service call. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
Daniel W Fairbanks , AK November 30, 2019 Quit working during self cleaning cycle After pulling the double oven out of the wall and disassembling the back to test the upper and lower thermostats (which I found to be working properly) I replaced the thermal fuse behind the display. It was inconvenient to pull the whole unit but there was no other way to be sure they were ok before the arrival of the thermal fuse. After a bit of internet research, I found that blowing the thermal fuse during self-cleaning is a common problem with KitchenAid/Whirlpool ovens (but there is strangely no mention of it in the owner’s manual). Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
David B Avon , NY December 26, 2018 Appliance: Whirlpool 30`` Built-In Electric Single Oven Non-Convection WOS51EC0AS00 No power after running self cleaning. Whirlpool in cabinet oven (WOS51EC0AS00). Lost power during self-cleaning. This is apparently common. It is an in-cabinet model so the fact that the door lock activated was the hardest to overcome -- cannot access screws to remove from cabinet with door locked. The only help I found was "use a coat hanger". I had no idea where the locking hook was though, but in the end I just inserted a coat hanger (a straight wire with an L bend with just less than an inch). Insert the wire at the top RIGHT side of the door, turn the L bend downward and slide the wire toward the left. The hook is in the middle and I actually got it on my first try! Removing the door: https://www.youtube.com/watch?v=zO7Rk9ODabw Thermal Fuse Replacement (Fuse-Thrml Part Number: AP6022801) https://www.youtube.com/watch?v=pfkamnQf8tw&t=131s After replacing the thermal fuse and turning the power back on, everything looked great. The control panel came on, the door lock unlatched, and I was able to turn on the oven, but the heat never came on. (Thrmst-Fix Part Number: AP6009390) Checking the blower would also be a good idea (Blower Part Number: AP6018081) Other good info: https://www.youtube.com/watch?v=XYeb9J09BVU This video also shows the Thermostat to some degree. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
