Whirlpool WPW10178809 Dryer Thermostat (155°F, Electric) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Dryer Fuse Or Sensor.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10178809 replaces AP6016375, W10178809, 4441710, PS11749662.

Description

This 155°F-rated electric dryer thermostat monitors and controls drum temperature. It cycles the heating element to maintain proper heat so loads dry consistently while helping protect the appliance from overheating.

• Regulates dryer temperature on electric models
• Controls heater cycling to maintain proper drying temperatures
• Failure may cause no heat or weak heat
• May lead to overheating or longer-than-normal dry times

What's included: 1 thermostat

• Disconnect power before servicing
• Access the thermostat for your model, note wire positions, and transfer connectors one at a time
• Mount the thermostat flat and secure for proper thermal contact
• Reassemble, restore power, and test a cycle for proper heating
