Whirlpool WPW10131836 Fixed Thermostat (140°F) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Dryer Fuse Or Sensor.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10131836 replaces AP6015488, W10131836, 4440810, PS11748767, WFR130116.

Description

This fixed, non-adjustable thermostat switches at approximately 140°F to control or limit temperature in the appliance. Replacing a fatigued thermostat restores accurate temperature regulation and helps prevent underheating, overheating, or erratic cycling.

• Senses temperature and changes state near 140°F to switch a circuit as designed
• Helps regulate heaters, fans, or act as an over-temperature protector
• Failure can cause no heat/low heat, runs too hot, or inconsistent cycling
• May prevent a fan or heater from turning on or off when expected

What's included: 1 thermostat Install notes:

• Disconnect power and allow components to cool before servicing
• Verify the temperature rating and terminal style match the original
• Note wire positions; transfer any mounting clips/insulators from the old part
• Ensure firm, clean contact with the mounting surface; avoid overtightening or flexing the disc
