Whirlpool WP9762794 Electronic Control Board (Oven) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP9762794 replaces AP6014136, 9762794, 1201919, PS11747371.

Description

This electronic control board manages core oven functions. It processes keypad inputs and controls heating so the oven starts, regulates temperature, and responds consistently when the original control has failed.

• Regulates oven heating cycles and sends power to bake and broil circuits
• Interprets keypad/touchpad selections to run chosen functions
• Uses oven sensor feedback to help maintain set temperatures
• Can help with symptoms like no heat, bake/broil won't start, unresponsive controls, or control-related error codes

Includes: 1 electronic control board

• Disconnect power at the breaker or unplug the appliance before servicing
• Electrostatic-sensitive part—use ESD protection and handle the board by the edges
• Note/photograph wiring and move connectors to matching terminals on the new board
• Restore power, set the clock, and verify all oven functions after installation
