Whirlpool W11213836 Gas Burner Venturi OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11213836 replaces AP6327597, W10512770, 4844504, PS12349337.

Description

This burner venturi channels gas from the valve orifice to the burner head and mixes in the right amount of air to produce a stable flame. Replace a corroded or clogged venturi to restore reliable ignition and flame quality.

• Directs gas from the orifice to the burner head and blends in combustion air
• Helps maintain an even flame pattern and consistent heat output
• Addresses weak/low or yellow flames, uneven heating, or delayed ignition
• Replaces venturis damaged by corrosion or blocked by spills/debris

What's included: 1 venturi Installation notes:

• Shut off gas supply and disconnect power before servicing
• Remove grates, caps, and burner head to access the venturi; remove per your model's procedure
• Note orientation and transfer any existing gasket/seal from the original part
• Reassemble, restore gas, check connections for leaks with a soap solution, and verify proper ignition and flame
