Whirlpool W10859921 Venturi (Surface Burner), 1 Per Package OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10859921 replaces AP5989910, 4383954, PS11731461, W10543959.

Description

This surface burner venturi mixes incoming gas with air and routes it from the orifice to the burner head. Replacing a worn or clogged venturi helps restore quick ignition and a steady, properly colored flame. What it does

• Connects the orifice to the burner head and directs gas flow
• Ensures proper air–gas mixing for clean, stable combustion
• Supports fast, consistent ignition
• When damaged or obstructed, symptoms can include weak or yellow flames, popping/lifting flames, delayed ignition, or a burner that won't light

What's included

• 1 venturi

Install notes

• Shut off gas supply and power; allow the cooktop/range to cool
• Remove grate, cap, and burner head to access the venturi
• Align the new venturi with the orifice; reuse model-specific screws/gaskets as applicable; do not overtighten
• Restore gas and check joints for leaks with a soap solution; verify proper burner ignition and flame quality
