Parts for Broan BCDF136SS: Wiring Diagram Parts

This replacement charcoal filter helps trap odors and grease particles in recirculating range hoods, restoring fresher kitchen air without ducting. Designed to fit compatible recirculating ventilation units for routine maintenance. What it does:

• Adsorbs cooking odors and airborne particles to reduce kitchen smells
• Improves perceived air freshness when exhaust cannot vent outside
• Helps maintain hood performance by capturing contaminants before they redeposit
• Recommended replacement when odors persist or filter appears saturated

• One charcoal (carbon) recirculating filter

• Follow your hood's service manual for filter access and replacement steps
• Ensure power to the hood is off before removing the old filter
• Dispose of the used filter per local regulations; do not attempt to wash or reuse
• Replace regularly as recommended by the manufacturer or when odors return

This install kit provides the hardware needed to mount and connect your ventilation appliance, helping secure the unit and complete the vent/duct connection for reliable operation. Useful when original installation parts are missing or damaged. What it does:

• Supplies mounting brackets, screws, and fittings to fasten and align the appliance
• Provides parts needed to complete the vent/duct connection and maintain airflow
• Replaces missing or damaged installation hardware that can cause loose mounting or noise
• Helps prevent gaps or misalignment that lead to air leaks or improper venting

• Turn off power to the appliance before beginning work and follow all safety precautions.
• Use common hand tools; some installations may require cutting or sealing of ductwork.
• Follow the original equipment manufacturer's installation instructions exactly.
