Parts for Ge WSM2700RDW: 01 - Console & Controls Parts

This mini manual dryer assembly replaces the original small clothes-drying unit on compatible GE compact dryers, restoring basic drying function in tight spaces. It provides the core drying components needed to resume routine lightweight loads safely and reliably. What it does:

• Replaces the dryer assembly that heats and circulates air for lightweight or compact drying cycles
• Restores basic drying capability when the dryer fails to start or produce warm air
• Helps resolve symptoms such as no operation from the dryer compartment or loss of drying performance
• Works with the appliance's existing controls and wiring when installed correctly

• One mini manual dryer assembly

• Disconnect power before attempting any service to avoid shock or injury
• Follow the appliance service manual for disassembly, wiring, and mounting instructions
• Inspect related components (wiring, fuses/thermal cutouts, vents) for damage before reassembly

Hex

This plug is an electrical wire connector that restores a secure, insulated connection between appliance wiring and components. It helps prevent intermittent power loss and reduces the risk of shorts from damaged or loose wiring. What it does:

• Provides a secure mating point for a component or harness to carry electrical power
• Insulates and protects exposed terminals from contact and shorting
• Replaces cracked, melted, or loose connector housings that cause intermittent operation
• Commonly used when a control, sensor, or motor has lost power due to a failed connector

• Always disconnect power at the breaker or appliance plug before inspecting or replacing electrical connectors
• Match the connector shape and terminal count to the existing harness to ensure proper fit
• Inspect surrounding wiring and terminals for heat damage; replace any damaged wires or terminals to prevent recurrence

Replace a failed dryer timer to restore reliable cycle selection and timing. This dryer control advances the machine through selected cycles so loads run and finish on the chosen program. What it does

• Advances the dryer through cycle steps and governs timed run lengths.
• Used for selecting timed and automatic cycles; coordinates cycle changes.
• Common symptoms: timer won't advance, dryer stays on one cycle, or cycles don't complete.
• Replace when the timer knob fails to turn or cycles no longer respond to controls.

• Disconnect power (unplug or shut off the breaker) before servicing to avoid electric shock.
• Access usually requires removing the control panel and unplugging the wiring harness; keep track of fasteners and connector locations.
• On gas dryers, shut off the gas supply before starting any work.
