Parts for Gaggenau EB964-610: 02 - Cavity Parts

This door lock assembly secures the dishwasher door and completes the start/operation circuit so the machine can run. Replacing a failed latch restores proper door closure and reliable wash-cycle starts. What it does:

• Mechanically latches the dishwasher door and holds it closed during operation
• Completes the electrical door-closed switch so the control will start and run cycles
• Commonly replaces locks that prevent the dishwasher from starting, show an unlocked error, or fail to stay latched
• Helps stop leaks and interruptions caused by a door that won't seal or lock

• One door lock assembly

• Disconnect power and water supply before starting work
• Access typically from the front: remove the door inner panel or control panel as needed
• Handle trim and mounting screws carefully; keep small fasteners and gaskets together
• After installation, verify the door latches securely and the dishwasher starts a test cycle

This halogen bulb socket connects and secures the oven light bulb so the interior light works reliably when the door is opened or the light switch is used. Replaces a worn or damaged socket to restore a solid electrical connection. What it does:

• Holds the halogen oven light bulb in place and provides the electrical contacts to power the lamp
• Commonly used when the oven light flickers, won't turn on, or the bulb becomes loose
• Maintains correct alignment and insulation for safe bulb operation
• Designed for direct replacement of the original socket in compatible ovens

• Disconnect power to the appliance before starting any repair to avoid electric shock
• Allow the oven and bulb to cool completely before touching components
• Handle halogen bulbs with a clean cloth or gloves; oils from skin can shorten bulb life

This Halogen Bulb is an OEM part for Bosch Ranges. It provides illumination for the range's interior. Continuous use or high temperatures can cause the bulb to burn out or fail.

What Causes a Bad Halogen Bulb:
Repeated heating and cooling cycles, along with continuous use, can cause the halogen bulb to burn out or break.

Symptoms of a Bad Halogen Bulb:

• The bulb is not lighting up
• Visible signs of damage or a broken filament
• Flickering or intermittent lighting

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This high-temperature 220V, 15-watt oven light bulb restores bright interior lighting so you can monitor cooking progress without opening the door. It's built for sustained heat and replaces a burned-out or flickering lamp.

• Illuminates the oven cavity during baking, broiling, and cleaning cycles
• High-temperature design for continuous heat exposure
• Common failure symptoms: no light when switched on, dim or intermittent illumination, blackened glass, or a broken filament

• Disconnect power at the breaker and allow the oven to cool completely
• Remove the light lens/cover; unthread and remove the old bulb
• Thread in the new bulb of the same voltage and wattage; do not overtighten
• Reinstall the cover, restore power, and test the light

This genuine mounting bolt secures appliance components and brackets to keep panels and assemblies fastened and stable for safe operation. A simple replacement for loose or missing hardware. What it does:

• Secures mounting brackets, panels or components in place to prevent shifting or rattling
• Restores proper fit where a worn, stripped or missing bolt caused loose parts
• Helps eliminate vibration noise and improve component alignment
• Matches OEM fit and function for reliable fastening

• Disconnect power and water before accessing the part
• Use the correct size wrench or socket to avoid rounding the head
• Tighten securely but do not over-torque; replace with same type if damaged
• If threads are stripped or mating parts are damaged, replace the mating hardware

This spacer positions and stabilizes nearby components to ensure proper fit and spacing during appliance assembly. It helps prevent rubbing and maintains correct panel and bracket alignment for quieter, more reliable operation. What it does:

• Keeps fixed parts correctly spaced to prevent contact and wear
• Stabilizes panels or brackets to reduce vibration and noise
• Restores proper alignment when gaps or looseness are present
• Supports fastener placement for secure reassembly

• Disconnect power and water before starting any repair
• Inspect surrounding hardware and replace any damaged fasteners before reinstalling the spacer
• Handle carefully to avoid deforming; install in original orientation and location

This gasket seals the heating element opening to help maintain proper heat and prevent leaks or debris entry. It restores a tight fit between the element and the appliance cavity for safer, more efficient operation. What it does:

• Creates a heat-resistant seal around the heating element to reduce heat loss
• Helps prevent dust, grease, and moisture from entering the element cavity
• Reduces risk of shorting or arcing caused by gaps or damaged insulation
• Common symptom fix: frayed, cracked, or missing gasket around element flange

• One heating element gasket

• Disconnect power (or unplug) and allow the appliance to fully cool before servicing
• Access the element per your model's service instructions; remove element mounting hardware to replace gasket if required
• Inspect element flange and mounting surface; replace gasket only if it matches OEM shape and seating
• If you see corrosion, burning, or element damage, replace the element as needed and retest after installation

This convection ring element heats the oven cavity for convection cooking, restoring even baking and broiling performance when the original element has failed. It replaces the circular heating element used with the fan-forced cooking system. What it does:

• Heats the oven cavity so heated air circulates for consistent baking and roasting
• Restores convection cooking performance when the ring element is burnt out or intermittent
• Can reduce uneven browning or undercooked spots caused by a failing element
• Works with the oven's fan and controls to maintain set temperatures during convection cycles

• 1 convection ring element

• Disconnect power to the range at the breaker before attempting any service
• Replace only after interior panels and fan access covers are removed per the service manual
• Handle the element carefully to avoid bending or damaging terminals; secure mounting hardware as found

This replacement gasket seals the dishwasher door to help prevent water leaks and keep wash cycles contained. It restores the door's watertight seal and helps reduce noise and moisture escape. What it does:

• Creates a watertight seal around the dishwasher door to help prevent leaks during operation
• Keeps spray and steam inside the tub for reliable cleaning performance
• Replaces cracked, flattened, or worn gasket material that can cause visible leaks
• Reduces moisture buildup and helps limit odors from trapped water

• One door gasket

• Disconnect power and water supply before starting any repair
• Remove the old gasket, clean the channel of debris and residue, then seat the new gasket evenly into the door channel
• Avoid using sharp tools that could nick the new seal; press firmly but gently to ensure full contact
• Run a short test cycle and inspect for leaks before returning the dishwasher to normal use

This fixing sheet is a small mounting plate used to secure internal panels or components in place, helping maintain proper alignment and reduce movement. It restores fit and stability where the original sheet is damaged or missing. What it does:

• Provides a secure mounting surface to hold panels, brackets, or components in place
• Helps prevent rattling, vibration, or misalignment caused by loose or missing hardware
• Restores factory fit where an original fixing sheet is bent, cracked, or missing
• Supports proper operation by keeping parts aligned and reducing wear from movement

• Designed for use in specific appliance locations; verify placement against your model's parts diagram
• Install with the correct screws or clips; retainers are not always included
• Disconnect power and water before accessing internal panels

This metal mesh grease filter captures airborne grease and large particles from range hood airflow to help keep the vent and exhaust path cleaner and reduce greasy buildup on internal components. What it does:

• Traps cooking grease and large particulates before they reach the blower or ducting
• Helps reduce greasy residue and buildup on internal hood surfaces
• Can improve airflow consistency when the filter is clean
• Common symptom: heavy visible grease, dark film on the filter, or smoke/odors not clearing effectively

• Turn off power to the range hood or vent before servicing
• Remove the old filter per the hood's access method (clips, slides, or screws), then insert the replacement securely
• Clean or replace regularly per the appliance owner's manual; do not operate with a damaged filter
