Parts for Amana ACM0860AB: 03 - Interior Controls Parts

This 15 amp, 250 volt replacement fuse protects your appliance's electrical circuits by interrupting power when a fault or overload occurs. It restores safe operation once the underlying issue is fixed and the fuse is replaced. What it does:

• Acts as an overcurrent protection device for circuits rated up to 15 A and 250 V
• Prevents damage to wiring and components by opening the circuit during an overload or short
• Common symptom: appliance has no power or specific functions stop working after a sudden failure
• Replacing a blown fuse can resolve intermittent power loss or complete power failure tied to a single blown element

• Disconnect power to the appliance before inspecting or replacing the fuse
• Replace only with a fuse of the same amperage and voltage rating to maintain safety and proper protection
• Use insulated tools and avoid touching live terminals; internal access may require disassembly, follow OEM service instructions
• If fuses blow repeatedly, stop using the appliance.

This propeller is the small impeller that mounts to the dishwasher circulation pump to move wash water through the spray arms for effective cleaning. Replacing a worn or damaged propeller restores proper water flow and wash performance. What it does:

• Spins on the pump shaft to circulate wash water through the spray arms
• Restores normal water flow when a cracked or stripped propeller reduces circulation
• Helps resolve symptoms such as poor cleaning, weak spray, or inconsistent water movement
• Works with the pump motor; does not include the motor or pump housing

• Disconnect power and water supply before beginning any repair
• Access the pump assembly from the dishwasher base or cabinet front per your model service instructions
• Inspect the pump shaft and seal for wear; replace damaged components to prevent repeat failure
• Reassemble carefully and test operation

This magnetron generates the microwave energy that heats food in a microwave oven. Replacing a failed magnetron restores normal cooking power and stops weak or no-heat performance. What it does:

• Converts high-voltage power into microwave radiation to heat food
• Restores full heating when poor or no heating is caused by a failed magnetron
• Addresses symptoms such as weak heating, no heating, or unusual humming/buzzing during operation
• Not a control board or transformer—this part is the microwave source component

• One magnetron (single unit)

• Disconnect power before servicing; microwave high-voltage components can hold a dangerous charge
• Handle the antenna/ceramic output carefully to avoid damage; inspect seals and waveguide components during replacement
• After installation, verify proper operation and safety features before normal use

This replacement capacitor restores stable electrical timing and motor/run performance in compatible Whirlpool appliances. It helps the appliance start and run smoothly when the original capacitor has failed or weakened. What it does:

• Provides the stored charge needed for motor start/run circuits and control timing.
• Helps prevent motor hum, slow starts, or failure to start when the capacitor is failing.
• Reduces erratic cycling or intermittent operation caused by a weak capacitor.
• Supports reliable operation of blower, fan or small motor circuits that rely on a dedicated capacitor.

• Disconnect power to the appliance at the source before accessing electrical components.
• Capacitors can hold charge—discharge safely before touching terminals.
• Use insulated tools and avoid shorting terminals; verify correct fit and secure connections.

15 Amp, 125/250 Volt. Package of 2. Switches have 3/16 inch terminals.

15 Amp, 125/250 Volt. Package of 2. Switches have 3/16 inch terminals.
