Parts for Maytag MMC5086AAS: 03 - Interior Controls Parts

This baseless light bulb restores the washer drum light so you can clearly see inside during loading and unloading. Replace a failed lamp to regain visibility and help prevent small items from being missed. What it does:

• Illuminates the washer drum when the light feature is activated
• Replaces a burned-out or damaged baseless lamp in the drum light assembly
• Common symptoms: light won't turn on, flickers intermittently, or the bulb appears darkened/broken
• Helps you check for remaining items after a cycle

• Includes 1 baseless light bulb

• Disconnect power to the appliance before servicing
• Allow the old bulb to cool completely before handling
• Access the drum light housing; pull the old bulb's leads straight out and insert the new bulb's leads fully into the socket
• Avoid touching the glass; handle the new bulb with clean gloves or tissue, then restore power and test

This 15 amp, 250 volt replacement fuse protects your appliance's electrical circuits by interrupting power when a fault or overload occurs. It restores safe operation once the underlying issue is fixed and the fuse is replaced. What it does:

• Acts as an overcurrent protection device for circuits rated up to 15 A and 250 V
• Prevents damage to wiring and components by opening the circuit during an overload or short
• Common symptom: appliance has no power or specific functions stop working after a sudden failure
• Replacing a blown fuse can resolve intermittent power loss or complete power failure tied to a single blown element

• Disconnect power to the appliance before inspecting or replacing the fuse
• Replace only with a fuse of the same amperage and voltage rating to maintain safety and proper protection
• Use insulated tools and avoid touching live terminals; internal access may require disassembly, follow OEM service instructions
• If fuses blow repeatedly, stop using the appliance.

This magnetron generates the microwave energy that heats food in a microwave oven. Replacing a failed magnetron restores normal cooking power and stops weak or no-heat performance. What it does:

• Converts high-voltage power into microwave radiation to heat food
• Restores full heating when poor or no heating is caused by a failed magnetron
• Addresses symptoms such as weak heating, no heating, or unusual humming/buzzing during operation
• Not a control board or transformer—this part is the microwave source component

• One magnetron (single unit)

• Disconnect power before servicing; microwave high-voltage components can hold a dangerous charge
• Handle the antenna/ceramic output carefully to avoid damage; inspect seals and waveguide components during replacement
• After installation, verify proper operation and safety features before normal use

This replacement capacitor restores stable electrical timing and motor/run performance in compatible Whirlpool appliances. It helps the appliance start and run smoothly when the original capacitor has failed or weakened. What it does:

• Provides the stored charge needed for motor start/run circuits and control timing.
• Helps prevent motor hum, slow starts, or failure to start when the capacitor is failing.
• Reduces erratic cycling or intermittent operation caused by a weak capacitor.
• Supports reliable operation of blower, fan or small motor circuits that rely on a dedicated capacitor.

• Disconnect power to the appliance at the source before accessing electrical components.
• Capacitors can hold charge—discharge safely before touching terminals.
• Use insulated tools and avoid shorting terminals; verify correct fit and secure connections.

15 Amp, 125/250 Volt. Package of 2. Switches have 3/16 inch terminals.
