Parts for Thermador CM302B: 03 - Upper Plenum Parts

This replacement fan restores proper airflow inside your appliance, circulating air for cooling and overall performance. Replacing a worn or damaged fan helps keep temperatures in check and reduces noise from rubbing or imbalanced blades.

• Circulates air as designed to cool components and move heat/moisture where intended
• Common symptoms of a failing fan include loud scraping or rattling, weak or no airflow, wobble, or the fan not turning
• Heat buildup around the control area or repeated thermal shutdowns can point to a fan issue
• Physical cracks, broken fins, or warping indicate the fan should be replaced

• Disconnect power at the breaker; allow the unit to cool completely
• Access the fan per your model; remove panels/guards carefully and note orientation
• Transfer any retaining nut/clip or gasket from the original as required; seat the fan fully and secure
• Spin by hand to verify free movement; ensure no contact with shrouds before restoring power

Oven not heating or overheating? A faulty thermostat disrupts temperature regulation. This replacement restores accurate oven temperature control.

This door switch interlock assembly is the door latch switch that detects and secures the dishwasher door so cycles can start and run safely. It restores proper door sensing and locking for normal operation. What it does:

• Detects when the dishwasher door is fully closed so the control will allow a wash cycle to start.
• Locks or interlocks the door during operation to prevent accidental opening and stop leaks.
• Helps resolve symptoms such as the dishwasher not starting, control lights flashing, or cycles stopping when the door is closed.
• Works as the electrical/mechanical interface between the door and the appliance control.

• One door switch interlock assembly

• Disconnect power to the appliance (unplug or shut off breaker) before beginning repair.
• Remove the dishwasher door panel or access panels as required to reach the latch; keep screws/fasteners organized.
• Align and secure the new interlock assembly and test door engagement and cycle start before reassembly.

Fix a loud humming or buzzing noise from your wall oven control panel. This low-voltage transformer powers the control board and related circuits.

Wall oven won't heat or stops heating mid-cycle? A faulty thermal fuse is often the cause. This safety component prevents overheating damage.

Replace a failed transformer cooling fan motor causing overheating issues. Circulates air to keep electrical components cool and maintain reliable operation.

This air interlock is the airflow switch that helps monitor and control dryer vent airflow, ensuring the appliance only runs when proper air movement is detected. It replaces a worn or failed interlock to restore normal vent sensing. What it does:

• Senses airflow through the vent and signals the control system to allow or stop operation
• Prevents dryer from starting or continuing a cycle when airflow is restricted
• Common symptom: dryer fails to start, stops mid-cycle, or shows poor drying performance
• Can help address intermittent operation caused by a faulty vent sensing switch

• Disconnect power before servicing to avoid electrical shock
• Handle the switch and wiring gently; verify connector orientation before reinstalling
• Confirm venting is clear and intact when replacing this part

This microwave high-voltage capacitor replaces the internal capacitor that stores and supplies the pulse of energy needed for the magnetron to generate microwaves. Restores proper HV circuit operation when the capacitor is faulty. What it does:

• Stores and releases high-voltage energy used by the microwave's magnetron
• Commonly fails after electrical stress, age, or arcing
• Symptoms of a failing capacitor: microwave not heating, intermittent operation, humming or arcing noises, or blown fuses
• Works with the high-voltage circuitry—do not use as a general-purpose capacitor

• Disconnect power and unplug the appliance before any service.
• Capacitors can retain dangerous voltage even when unplugged—discharge safely using an insulated discharge tool.
• Follow the appliance service manual for correct removal and wiring; replace with the exact OEM part.

Microwave not heating? A failed diode rectifier prevents proper power flow to the magnetron. This one-way current component is essential for heating function.

Microwave stirrer blade assembly distributes heat evenly during cooking. Replace if you notice hot or cold spots in heated food. Verify fit with your model number before ordering.
