Parts for Thermador PRG304US: 04 - Bottom Frame Parts

This genuine-style door gasket seals the dishwasher door to the tub to help prevent leaks and maintain proper wash performance. It restores a snug, even seal when the original gasket is cracked, torn, or worn. What it does:

• Creates a watertight seal between the dishwasher door and tub to reduce leaks during cycles
• Helps maintain consistent wash and dry performance by keeping water and steam inside the tub
• Reduces door rattling and dampens vibration caused by a compressed or damaged seal
• Common symptom: water pooling or dripping from the door edge, visible tears, gaps, or persistent odor from trapped moisture

• One door gasket / seal

• Disconnect power and water to the appliance before attempting any service
• Remove the inner door panel or access trim per your model's service instructions to replace the gasket
• Check the gasket seating channel for debris or damage and clean before installing the new seal

This orifice is the small, calibrated gas jet used in the oven burner to control natural gas flow for proper combustion and consistent heat. It replaces a worn or clogged orifice to help restore reliable oven ignition and baking performance. What it does:

• Directs and meters natural gas to the oven burner for correct flame size and stability
• Helps resolve symptoms like weak or uneven burners, weak ignition, or yellow/sooting flames when caused by a restricted orifice
• Used on the oven top/burner assembly where a #38 sized jet is specified
• Fits into the burner orifice holder and works with the existing regulator and valve

• Install only after shutting off the gas supply and following all safety procedures; check for leaks with a soapy water solution or approved leak detector
• Use correct tools and avoid damaging the orifice tip; thread carefully to prevent cross-threading
• Do not modify the orifice; replace with the exact specified size to maintain safe operation

The Oven Burner Igniter is an OEM part for Bosch ranges. This part ignites the gas burner to provide the necessary heat for cooking. The igniter works by heating up and creating a spark that ignites the gas, ensuring efficient and reliable operation of the oven.

Causes of a bad igniter can include regular wear and tear, damage from repeated heating cycles, or issues with the electrical connections.

Symptoms of a bad igniter include:

• The oven not heating up
• Difficulty igniting the burner
• The burner not staying lit
• Unusual clicking or sparking noises during ignition

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

Support, hinge counter restores proper hinge support and door balance for a worn or damaged hinge assembly. This replacement helps the appliance door open and close smoothly and stay aligned for reliable everyday use. What it does:

• Provides structural support to the door hinge and helps counterbalance the door
• Stabilizes hinge movement to reduce sagging, binding, or uneven closing
• Helps the door latch and seal correctly by keeping the hinge alignment consistent
• Use when you notice door droop, difficulty latching, or irregular door motion

• Installation may require partial disassembly of the door or hinge assembly—refer to the OEM instructions for your model
• Disconnect power and turn off water supply before beginning any repair
• Inspect surrounding hinge components and fasteners; replace any damaged parts and test door operation after installation

This glow igniter heats electrically to light the appliance's gas burner. A weak or failed igniter can stop ignition or cause very long preheat times; replacing it restores reliable burner lighting and proper heating performance.

• Heats to a bright glow to ignite the gas burner
• Common fix for oven not heating or burner not lighting
• Often resolves long preheat times or intermittent ignition
• If the igniter doesn't glow—or glows but no flame appears—it may be weak or failed

• Disconnect power and shut off gas before servicing; allow the unit to cool completely
• Handle the ceramic element carefully; avoid touching the igniter surface and do not flex, drop, or strike it
• Transfer any reusable mounting hardware and wiring/connectors from the old part as needed
• Verify secure connections and proper positioning near the burner before restoring power and gas
