Parts for Ge AZ22E15D2CM1: 04 - Section4 Parts

This evaporator assembly is the sealed coil assembly that removes heat from the refrigerator freezer compartment to help maintain proper cooling. Replacing a damaged or corroded evaporator restores the cooling surface for the refrigerant. What it does

• Circulates refrigerant through the freezer evaporator coil to absorb heat from the compartment.
• Enables proper frost/defrost cycles when installed with the appliance's defrost system.
• Restores cooling when a visibly damaged, leaking, or heavily corroded evaporator coil is the cause.
• Helps reduce frost buildup and temperature rise related to a failing evaporator.

• Disconnect power to the appliance before starting any repair.
• Access requires removing interior panels and possibly the evaporator cover; save fasteners for reassembly.
• Avoid bending or puncturing the coil; damaged tubing can release refrigerant and require licensed service.

A rubber compressor cushion that isolates the compressor from the refrigerator chassis to reduce vibration and prevent metal-on-metal contact. Replaces worn or missing cushions to help minimize noise and vibration transfer. What it does:

• Cushions the compressor to dampen vibration and reduce rattling or buzzing noises.
• Keeps the compressor from directly contacting the cabinet, preventing wear and chafing.
• Helps maintain proper compressor positioning and reduces stress on mounting components.
• Common symptom: increased compressor noise or vibration, or visible worn/deteriorated cushion.

• One compressor cushion (rubber mount).

• Disconnect power to the appliance before starting any repair.
• Support the compressor or secure the unit when removing/replacing mounts to avoid strain.
• Remove the old cushion and press the new cushion into place; no refrigerant handling required.
• Use basic hand tools and wear gloves.
