Parts for Thermador CGBD48RX: 10 - Outer Burner Box Parts

Gas won't flow to burners or grill? This 48-inch gas supply tube connects the inlet to the valve, restoring safe fuel delivery when the original is damaged.

Bulkhead elbow fitting that connects gas lines in your range or cooktop. Replace if cracked, leaking, or damaged to restore proper gas line connections.

The Spark Ignition Switch is an OEM part for Bosch ranges and cooktops. It controls the ignition of surface burner flames by emitting an electrical spark when activated.

Causes of a bad switch can be general wear and fatigue over thousands of start cycles. Exposure to moisture, dust or metal debris could also damage electrical components internally.

Symptoms of a bad spark ignition switch include:

• Burners failing to light even when valves are turned on
• Intermittent or irregular lighting of some burners
• No electrical sparks emitted from the ignition electrode

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

If your burners won't ignite or flames are weak, a damaged gas supply tube may be blocking fuel flow. This 9-inch tube restores proper gas delivery. 2-hour DIY repair.

Saddle clamp secures gas lines and wiring on cooktops and ranges. Replace if cracked, loose, or missing to prevent rattling and ensure safe operation.

Tube coupling connects gas lines in grills and smokers. Replace if cracked, leaking, or corroded. Essential for safe fuel line connections and proper fit.

Controls gas supply pressure to burner manifold. Replace if regulator is cracked, sticking, or no longer maintaining correct pressure for consistent flames.

This is a flexible gas inlet hose used to supply gas to the burners in a range or oven. It connects the gas valve assembly to the burner manifold, ensuring a secure and leak-free fuel path. Replace this hose if you detect a gas smell near the appliance, notice visible cracking or deterioration, or if the burners are not receiving adequate gas flow.

Venturi tube for gas ranges and cooktops. Mixes gas and air for proper burner combustion. Replace if cracked, corroded, or threads are damaged.

This igniter creates the spark needed to light gas burners on your range cooktop. It generates an electric arc that ignites the gas flow when you turn the burner control knob. Replace this part if burners won't light, take multiple attempts to ignite, or produce weak clicking sounds without lighting.

The Igniter Mounting Clip is an OEM part for Bosch ranges. It secures the igniter to the range top, ensuring it is properly aligned and stable for optimal ignition performance. The surface igniter is crucial for the ignition of gas burners, facilitating an immediate and safe flame to cook with.

Over time, the Igniter Mounting Clip can succumb to various forms of wear and tear, including corrosion from exposure to moisture, degradation from frequent heating cycles, or physical damage during cleaning or maintenance activities.

Symptoms of a compromised Igniter Mounting Clip include:

• The surface igniter becoming loose or dislodged
• Difficulty in igniting the burner or uneven flames
• Noisy or irregular ignition sounds
• Visible signs of damage or corrosion on the clip

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

Used to hold down the jet holder assembly.

Jet holder securely houses the orifice assembly on gas range burners. Replace if cracked, corroded, or heat-damaged. Ensures proper gas flow and ignition.

This LP main jet regulates propane flow to a surface burner to maintain a clean, stable flame. Replace a clogged or incorrect jet to restore proper burner performance, especially when converting a cooktop or range from natural gas to LP.

• Meters LP gas to the burner head for correct flame size and combustion
• Direct replacement for a damaged, clogged, or incorrect jet during service or LP conversion
• May help with yellow/sooty flames, weak or overly high flames, uneven heating, or delayed ignition

• Shut off gas and power; allow the appliance to cool completely
• Remove grates, caps, and burner head to access the orifice holder
• Start the jet by hand, then tighten gently with the correct tool—do not overtighten
• After installation or any LP conversion, leak-test connections and verify a steady blue flame; other jets and the regulator may also require LP settings per the model's instructions

The gas supply tube delivers gas from the main line to the range burners and is located behind or underneath the unit. Replace if you smell gas, notice uneven flame patterns, or if the tube shows signs of corrosion or damage during inspection.

This is a gas tube or connector used in a range or cooktop to route gas from the supply line to the burner assembly. It ensures a secure, leak-free connection for proper gas flow. Replace this part if you detect a gas smell near the appliance, experience uneven flame, or notice visible damage or corrosion on the existing tube.

This is a 12-foot power supply cable designed to connect a range or cooktop to an electrical outlet. It provides the necessary electrical connection for the appliance to operate safely. Replace this cable if it shows signs of fraying, damaged insulation, exposed wires, or if the appliance intermittently loses power.

The Grate Foot Kit is an OEM part for Bosch ranges. This kit includes the small rubber feet that attach to the bottom of the range grates, providing stability and preventing the grates from scratching the range surface.

Over time, the grate feet can wear out or become damaged due to exposure to high temperatures, regular cleaning, or accidental impact. Missing or worn-out feet can cause the grates to sit unevenly or scratch the range surface.

Symptoms of a bad grate foot kit include:

• The range grates sitting unevenly or wobbling
• Scratches or damage on the range surface
• Grates sliding or shifting during cooking
• Missing or visibly worn-out rubber feet

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.
