Parts for Thermador RDDS30: 14 - Burner Box Parts

This right-side control panel endcap replaces a cracked, faded or loose trim piece to restore the dishwasher's appearance and help keep the control area protected from moisture and debris. It matches the OEM shape and finish for a clean fit. What it does:

• Replaces a damaged or missing right control-panel endcap to restore cosmetic appearance
• Helps keep moisture and food debris away from edges of the control panel
• Secures the control panel trim so buttons and switches align correctly
• Prevents further chipping or cracking around the control-panel edge

• Disconnect power to the appliance before servicing to reduce shock risk
• Typically installed by removing the outer door panel or release clips—do not force the part into place
• Keep OEM screws and retainers; replace any damaged fasteners for a secure fit

This vacuum thermostat is a small control switch that helps regulate temperature-related vacuum signals in compatible appliances, restoring proper cycling and control for critical functions. Designed as a direct-fit replacement when the original fails. What it does:

• Senses vacuum/temperature conditions and opens or closes the control circuit as needed.
• Helps ensure proper defrost, evaporator, or control-system cycling when used in applicable systems.
• Commonly replaced if the appliance shows intermittent cycling, erratic temperature control, or related control failures.
• Matches OEM form and function to restore reliable operation when the original thermostat is faulty.

• One vacuum thermostat (single replacement unit)

• Disconnect power to the appliance before accessing electrical components to avoid shock.
• Handle carefully to avoid damage to terminals or the sensor element; avoid bending or stressing mounting tabs.

This part has been discontinued by the manufacturer and is no longer available.

This small mounting bracket secures the vacuum (vac) switch in place, keeping the switch stable and properly positioned for reliable pressure sensing. Replacing a worn or broken bracket restores correct switch alignment and function. What it does:

• Holds the vacuum/pressure switch securely to the appliance chassis
• Keeps vacuum tubing and switch terminals aligned to prevent kinks or strain
• Helps maintain consistent pressure sensing for proper system operation
• Commonly needed when the original bracket is cracked, broken, or missing

• Designed for direct replacement; match the bracket to the switch mounting points before installing
• Power off and disconnect the appliance before accessing internal components
• Handle vacuum tubing and switch gently—avoid kinking or stretching lines

This part has been discontinued by the manufacturer and is no longer available.
